The Theben AMUN 716 S KNX is a CO2 air quality sensor with integrated individual room thermostat for measuring CO2 level, relative humidity, temperature and barometric air pressure.
Function description
- CO2 airquality sensor with integrated individual room thermostat
- Measures CO2 level, relative humidity, temperature and barometric air pressure
- Three independent, configurable thresholds for the CO2 level and relative humidity
- CO2 setting range of 300-5000 ppm
- Actions can be carried out if thresholds are exceeded or not reached (send, priority, switching, value)
- For controlling heating actuators or motorised actuators
- Two front panels are included in delivery: a numerical and a relative scale
- Manual override button for presence or operation modes: comfort, stand-by, temperature reduction at night, frost protection
- 4 binary inputs for conventional switches/sensors (switching, dimming, blinds), also for externeal temperature sensor, window contact or presence signal
- Display of the current operating mode and heating/cooling mode through multi-colored LED
Technical data
|
| Operating voltage KNX |
Bus voltage, ≤15 mA |
| Measuring range CO2
|
300 – 5000 ppm |
| Setting range temperature |
-5°C ... 45°C |
| Measuring range humidity |
1 – 100 % rH |
| Measuring range air pressure |
30000 – 110000 Pa |
| Interface extension max. |
30 m |
| Contact voltage |
5 V Internal provided |
| Contact current |
0.5 mA |
| Ambient temperature |
5°C ... 40°C |
| Installation type |
Wall installation |
| Display |
LEDs mehrfarbig |
| Type of protection |
IP 20 |
| Protection class |
III according to EN 60 730-1 |
