The KNX USB Interface 312 is a data interface between a PC or laptop and the KNX installation bus. It can be used as a programming interface for ETS® Software Version 3 (or higher) and supports KNX long frames. Long telegrams enable a faster download to devices that can receive these telegrams.
The LEDs on the device indicate the operating status and communication errors on the bus. The USB connector is galvanic isolated from the KNX bus.
Technical data
Mechanical Data
- Housing: plastic
- DIN rail mounted device, width: 1 TE
Indicators
- LED (multicolor) for USB
- LED (multicolor) for KNX
KNX
- Medium TP
- Long Frame
- Object Server: BAOS V2
- Device model: System B
Power supply
Connectors
- KNX connector
- USB connector type B
Compatibility
- ETS (Engineering Tool Software) ETS3 or later
- Falcon Driver (KNX Association)
