single device, not suitable for combinations with integrated 1-gang frame LS 990
Intended use
Operating loads and displaying the status of systems and information e.g. light switching, dimming, controlling blinds/shutters, temperature and consumption values etc. Measurement and feedback control of the room temperature. Installation in flush box with dimensions according to DIN 49073.
Product characteristics
- High resolution IPS colour display
- Capacitive touchscreen
- Function of favourites page adjustable (without ETS)
- Max. 32 operating functions switching, dimming, controlling blinds, value transmitters, calling up light scenes, etc.
- Integrated room temperature sensor
- Room temperature control with setpoint value specification
- Alarm function (optical and/or acoustic)
- Max. 8 timer functions can be activated and set (depending on time, astronomical clock or random)
- Integrated proximity and brightness sensor
- Integrated bus coupling unit
- Connection of installation buttons or reed contacts possible
- Commissioning and support of KNX Data Secure with ETS from version 5.7.4
- Display of room temperature and setpoint temperature
- External sensor (ref.-no.: FF NTC) can be connected
- Display of outdoor temperature – with external sensor, e.g. weather station
- In combination with JUNG Visu Pro software "Multi-Room Control": music play control, display of music titles, artists, etc.
Technical data
- Height above surface: 12 mm
- Screen diagonal: 86 mm / 3.4’’
- Resolution: 320 x 310
- Recommended mounting height: 1.5 m
- KNX
- KNX medium: TP 256
- Security: X-mode
- Commissioning mode: S-mode
- Rated voltage: DC 21 ... 32 V SELV
- Current consumption KNX: 60 mA
- Connection, KNX: NaV
- Connection cable: EIB-Y (St)Y 2x2x0.8
- Protection class: III
- Connecting external switching contacts
- Number: max. 20
- Connection cable: EIB-Y (St)Y 2x2x0.8
- Cable length: max. 25 m
- Ambient conditions
- Ambient temperature: −5 ... +45 °C
- Stora/transport temperature: −25 ... +70 °C
- Relative humidity: 30 % ... 70 %
